Solutions for low screen resolution in Ubuntu 14.04/14.10 and VirtualBox

Xdiagnose Ubuntu 14.10

This article was originally posted on the forum.

On my test installations of Ubuntu 14.04 in VirtualBox, I had to figure out how to deal with a situation where the highest screen resolution I could get was 640 x 480. And it was not just with Ubuntu 14.04, but also with Kubuntu 14.04.

UPDATE: This also applies to Ubuntu 14.10.

This image shows the output of the <strong>xrandx</strong> command.
Output of xrandx Ubuntu 14.04

Here’s what it looks like from the Display module of System Settings. That’s not good. I found that there are two solutions to the problem.
System Settings Ubuntu 14.04

1. Use Xdiagnose From the Dash, search for and launch Xdiagnose, then enable all the options under the Debug section. Click the Apply button, then close the window and restart the system. You’ll have to restart. Logging out, then in won’t do.
Xdiagnose Ubuntu 14.10

2. Additional Drivers Also from the Dash, search for and start Software Updates. Click on the Additional Drivers tab, then click on the Using x86 virtualization solution…. Apply the changes, then restart the machine.
Additional Drivers Ubuntu 14.04

With either solution, the system should reboot in 1024 x 768 screen resolution. And you should be able to expand the window simply by dragging it. If you run the xrandx command again, the output should be just like the one shown in this image:
xrandx Ubuntu 14.04

Share:

Share on facebook
Facebook
Share on twitter
Twitter
Share on pinterest
Pinterest
Share on linkedin
LinkedIn

Partner links

Newsletter: Subscribe for updates

Subscribe
Notify of
guest
70 Comments
Inline Feedbacks
View all comments
Rob Scott
Rob Scott
3 years ago

First solution (X Diagnostics settings) worked for me. Linux Ubuntu 16.04 at 64 bit on an MSI AMD motherboard. Samsung SyncMaster 932GW Monitor. Thank you.

Brian
Brian
4 years ago

Thank you, Solution #1 did it for me.
Very grateful for your info.

Joe Campbell
Joe Campbell
4 years ago

It broke the OS the first time I restarted, but when I restarted again it all worked. Lol

Mike
Mike
4 years ago

Wow, that just killed my system. It stays black now. Thank you!

juanhdv
juanhdv
5 years ago

Great! A genius!
